Modelling populations

There are plenty of statistics about population. If we concentrate on birth and death rates of 'cohorts' of males and females, ie those in certain age groups, we can model how the total population changes with time. Then throw in plagues, wars etc at random. Or immigrants arriving as economic migrants, or escaping from war-torn countries. Or introduce compulsory euthanasia at ag 70. Or tax children to limit birth rates. All goo clean fun..



    'populater7          8 Feb 2006

    'draws and updates population pyramids as cohorts ( 5 year groups)
    '   are born, die or have children.

    'put in real data to watch, or implement your own eugenics
    '   eg kill everyone off when they reach 40
    '   or enforce 1 child per family...

    'a work-in-progress

    'let me know of any ideas to improve it.

nomainwin

dim men( 20), women( 20), drm( 20), drw( 20), brm( 20), brw( 20)
'   population, death rates of men & women in each cohort,
'   and birth rates of male & female babies (so I can include
'   eugenics like choosing male babies as a preference!)

global future, currentpop, delay, deltap

for cohort =0 to 19 '            The start data can easily be changed . . . .
    read a:   men( cohort) =a   'number of males in cohort
    read a: women( cohort) =a   'females
    read a:   drm( cohort) =a   'death rate for males in cohort
    read a:   drw( cohort) =a   'females
    read a:   brm( cohort) =a   'birth rate of   male babies to girls in cohort
    read a:   brw( cohort) =a   'birth rate of female babies
next cohort

'       pop  pop  drm drw  brm  brw
'       num  num  %     %    %    %
data    50,  50,   2,   2,   0,   0 ' cohort zero   ages  0 to 4
data     0,   0,   1,   1,   0,   0 ' cohort one    ages  5 to 9
data     0,   0,   1,   1,   2,   2 ' cohort 10 to 14   first fertile cohort
data     0,   0,   1,   1,   7,   7 ' cohort 15 to 19
data     0,   0,   2,   1,  21,  21 ' cohort 20 to 24   men are silly at this age...
data     0,   0,   1,   1,  30,  30 ' cohort 25 to 29   NB I assume equal m/f birth rate- with no selection they are within 3% of each other, females higher

data     0,   0,   1,   1,  33,  33 ' cohort 30 to 34
data     0,   0,   1,   1,  12,  12 ' cohort 35 to 39
data     0,   0,   1,   1,   6,   6 ' cohort 40 to 44
data     0,   0,   1,   1,   1,   1 ' cohort 45 to 49

data     0,   0,   5,   5,   0,   0 ' cohort 50 to 54
data     0,   0,   8,   7,   0,   0 ' cohort 55 to 59  About here death rates start to rise . . .
data     0,   0,  12,   9,   0,   0 ' cohort 60 to 64    but less for women than for men . . . .
data     0,   0,  18,  11,   0,   0 ' cohort 65 to 69
data     0,   0,  28,  15,   0,   0 ' cohort 70 to 74
data     0,   0,  40,  28,   0,   0 ' cohort 75 to 79
data     0,   0,  70,  50,   0,   0 ' cohort 80 to 84
data     0,   0,  80,  65,   0,   0 ' cohort 85 to 89
data     0,   0,  90,  70,   0,   0 ' cohort 90 to 94
data     0,   0,  98,  95,   0,   0 ' cohort 95+

WindowWidth  =880
WindowHeight =620

UpperLeftX   =INT( ( DisplayWidth  -WindowWidth)  /2)
UpperLeftY   =INT( ( DisplayHeight -WindowHeight) /2)


menu #jf, "&File", "E&xit",  [quit]
menu #jf, "&Help", "&About", [about]

graphicbox #jf.g5,  203,  82,  16, 200
graphicbox #jf.g,    10,  70, 400, 220
graphicbox #jf.g2,   10, 310, 400, 204
graphicbox #jf.g3,  520,  10,  50,  50
graphicbox #jf.g4,   10, 300, 400,   8


textbox    #jf.t1,   10,  30, 400,  30
textbox    #jf.t2,   10, 520, 400,  30

texteditor #jf.t3,  420,  70, 440, 460

button #jf.delayup, "Slower",     slower, UR, 380, 34
button #jf.delaydn, "Faster",     faster, UR, 380,  8
button #jf.war,     "War!",          war, UR, 260,  8
button #jf.famine,  "Famine!",    famine, UR, 180,  8
button #jf.boom,    "Baby boom!",   boom, UR,  80,  8
button #jf.over,    "Boom over!",   over, UR,  80, 34
button #jf.plague,  "Plague!",    plague, UR, 180, 34

open "Population Modeller-  'Populater'    JohnF    Feb 2006." for window_nf as #jf

print #jf,    "trapclose [out]"
print #jf.g,  "size 4"
print #jf.t1, "!font courier_new 16 bold"
print #jf.t2, "!font courier_new 8"
print #jf.t1, "     Females  ...  Males"
print #jf.t3, "!font courier_new 8"

open "Malthus.txt" for input as #autoexec
print #jf.t3, "!contents #autoexec";
close #autoexec

delay  =50000
deltap =    0

print #jf.g2, "down ; size 2 ; color black ; line 0 198 400 198 ; line 2 198 2 10"
print #jf.g3, "cls ; backcolor yellow ; fill green ; goto 25 25 ; down ; circlefilled "; str$( int( 2 +delay /4000))

cp    =    0

for future =0 to 200
    cp =currentpop
    call update5years   'display current situation

    for d =0 to delay  'increase to delay each update
        scan
    next d

    if future =0 then
        notice "Just a notice!" + chr$(13) + "Holding start display." +chr$(13) +"Click to proceed!"
    end if

    century =int( cp /100)  ' horizontal every 100 pop'n
    print #jf.g2, "down ; size 1 ; color darkgray"
    print #jf.g2, "line 0 "; str$( 200- 10 *century); " 400 "; str$( 200 -10 *century); "up"

    call generation
    scan
    deltap =int( currentpop -cp) '  rate of growth
next future

[quit]
print #jf.g,  "flush"
print #jf.g, "getbmp pyramid 1 1 399 219"
filedialog "Save pyramid as", "pyramid*.bmp", p$
if p$ <> "" then bmpsave "pyramid", p$
print #jf.g2, "flush"
print #jf.g2, "getbmp graph 1 1 399 203"
filedialog "Save graph as", "graph*.bmp", g$
if g$ <>"" then bmpsave "graph", g$
[out]
confirm "Are you ready to QUIT?"; rv$
'and if No??
close #jf
end

sub update5years
    #jf.g, "cls"
    'Add a routine to put on cohort ages, so the scale/ ages are obvious.
    #jf.g5, "down ; font Times_New_Roman 7"
    for m =0 to 95 step 5
        #jf.g5, "goto 4 "; str$( int( 2.0 *( 100 -m) -5))
        #jf.g5, "\"; str$( m)
    next m
    type =0
    if deltap >10  then type = 1
    if deltap <-10 then type =-1
    select case type
        case 1
             #jf.g4 "fill green"
        case -1
            #jf.g4 "fill red"
        case 0
            #jf.g4 "fill white"
    end select

    if abs( ( future *5 /100) -int( future *5 /100)) <0.01 then ' vertical grid every 100 years
        print #jf.g2, "down ; size 1 ; color darkgray ; line "; str$( future *2); " 10 "; str$( future *2); " 198"
    end if

for cohort =0 to 19
    print #jf.g, " down ; color "; str$( cohort/20 *255); " "; str$( cohort/20 *255); " 255"
    print #jf.g, "line 210 "; str$( 210 -cohort *10); " "; str$( 210 +2*  men( cohort)); " "; str$( 210 -cohort *10)

    print #jf.g, "color 255 "; str$( cohort/20 *255); " "; str$( cohort/20 *255); " ; down"
    print #jf.g, "line 190 "; str$( 210 -cohort *10); " "; str$( 190 -2*women( cohort)); " "; str$( 210 -cohort *10)
next cohort
end sub

sub generation
    currentpop =0

    for cohort =19 to 1 step -1 'each cohort moves up and some die
          men( cohort) =   men( cohort -1) *(100 -drm( cohort -1))/ 100
        women( cohort) = women( cohort -1) *(100 -drw( cohort -1))/ 100
    next cohort

      men( 0) =0
    women( 0) =0

    for cohort =0 to 19 'and others are born
         men( 0) =  men( 0) +brm( cohort)/ 100 *women( cohort)
       women( 0) =women( 0) +brw( cohort)/ 100 *women( cohort)
       currentpop= currentpop +men( cohort) + women( cohort)
    next cohort

    print #jf.g2, "down ; size 2 ; color blue ; set "; str$( 4 +2 *future); " "; str$( 200 -int( currentpop /10))
    print #jf.t2, 5 *( future +1); " years ahead. The population now is "; int( currentpop); " & change "; deltap
end sub

sub faster buttonhandle$
    if delay >100 then delay =delay *0.8
    print #jf.g3, "cls ; fill green ; goto 25 25 ; down ; circlefilled "; str$( 2 +int( delay /4000))
end sub

sub slower buttonhandle$
    if delay <100000 then delay =delay *1.2
    print #jf.g3, "cls ; fill   red ; goto 25 25 ; down ; circlefilled "; str$( 2 +int( delay /4000))
end sub

sub war buttonhandle$ ' Modern war kills all ages, but especially men 15 to 30
    for cohort =0 to 19
          men( cohort) =  men( cohort) *0.8
        women( cohort) =women( cohort) *0.8
    next cohort
    for cohort =3 to 6
          men( cohort) =  men( cohort) *0.7
        women( cohort) =women( cohort) *0.7
    next cohort
end sub

sub famine buttonhandle$
      men( 0) =  men( 0) *0.1
      men( 1) =  men( 1) *0.2
    women( 0) =women( 0) *0.05 ' girl babies are seen as less important!
    women( 1) =women( 0) *0.1
    for cohort =2 to 10 '   Parents try to feed children and starve themselves & the old
          men( cohort) =  men( cohort) *0.6
        women( cohort) =women( cohort) *0.6
    next cohort
    for cohort =11 to 19
          men( cohort) =  men( cohort) *0.3
        women( cohort) =women( cohort) *0.3
    next cohort
end sub

sub boom buttonhandle$ '    all birth rates up 50%
    for cohort =2 to 10
        brm( cohort) =brm( cohort) *1.5
        brw( cohort) =brw( cohort) *1.5
    next cohort
end sub

sub over buttonhandle$ '    all birth rates down 50%
    for cohort =2 to 10
        brm( cohort) =brm( cohort) *0.67
        brw( cohort) =brw( cohort) *0.67
    next cohort
end sub

sub plague buttonhandle$ ' Hits old and young disproportionately
    for cohort =0 to 4
          men( cohort) =  men( cohort) *0.5
        women( cohort) =women( cohort) *0.5
    next cohort
        for cohort =5 to 12
          men( cohort) =  men( cohort) *0.8
        women( cohort) =women( cohort) *0.8
    next cohort
    for cohort =13 to 19
          men( cohort) =  men( cohort) *0.5
        women( cohort) =women( cohort) *0.5
    next cohort
end sub

You also need the following text saved as 'malthus.txt''


  ******************************************************

  ******  Population Growth displayed as Pyramids ******



 The pyramid is the traditional way to look at populations.

 Population is displayed as the number of males and
 females in 20,  5-year 'cohorts'.
 This is usually used statically, to show as a snap
 shot the present situation, or as an animation of
 past data & future predictions.

 A steeply declining pyramid indicates Third World.
 High numbers of births but high death rates.

 The developed world tends towards a shape with few
 deaths until late middle age.

 Population growth, and the growth and decline of
 nations, have fascinated mankind for millennia.
 Scientists like Malthus first seriously raised
 some of the issues, picked up later in the Sixties
 by the Club of Rome..


 Have you now seen the population, which started
 as a very unusual distribution, evolve into
 the classic 'developed world' shape?

 You may now care to reduce the delay loop so
 a complete run is faster, if you simply want
 to see the trend.

 Did you notice females dying off later than males?
     Unfair!!
 Did you notice teenage males die off rather quickly?
     What can you do about that?


 I am part of the 'baby boom' bulge immediately
 after WW II. You can see 'echoes' of that still
 in European & US pyramids.



 It is inevitable, since I've built in our
 typical current Population dynamics.
 They mean that whatever unlikely
 start population you try, you will end with
 exponential growth or decay.

 Total population will not be static without
 continual changes- natural or otherwise.
 It is almost impossible to get a balance,
 except by social feedback continually
 altering the death and birth rates.

 The added buttons give you a chance to try to
 stabilise population.
 I assume starvation hits all ages but parents
 starve themselves to feed middle-aged-children
 while babies starve.
 Wars hit almost all ages now- they used to kill
  mainly men from 15 to 35.
 Baby boom is a sudden confidence or wealth which
 makes lots of families decide to have more children.
 End of boom is when a recession or similar reduces
 everyone's confidence in the future.


 Be extreme!
    Kill everyone off at 40!
    Insist on exactly two babies per couple!!
 All you have to do is try different
 birth and death rates-
 and NO-ONE need die or be killed!

 No rigid arrangement can be stable....
 Traditionally the natural controls were the
 Four Horsemen of the Apocalypse.
    Famine
       War
          Pestilence
             Death ( of natural causes)

 'Civilisation' has increasingly affected all of these,
 but it has also created new cultural expectations.
 We are exposed far less now in our 'First World' to
 the high incidence of the first three Horsemen that
 even our parents experienced; and natural death rates
 are significanly better than even fifty years ago.

 I can thoroughly recommend some websites for further
 appraisal. Some have data for different countries, and
 many have lovely Java animations similar to my LB.
 But you cannot tinker with the rates in their closed
 simulations- which is why I knocked up this one.



 NB I have assumed that birth rates depend on the number
 of females ( and birth rates) only.
 In practice, if there is a shortage of men relative to
 women it will reduce birth rates a bit- and if there are
 no men then clearly there can be no births.
 I have also not included information about male
 fertility or relative ages of typical couples...

 Some day????


 _______________________________________________________________

			To-dos

  Add a cohort label down the centre.
  Flush in case another window is moved over.
  Make the display of labels and values of year and pop. look better.
  Add a library of rates.csv for real countries rather
      than use data statements.
  Add an option to scale vertically logarithmically so you get a
      straight line and see small-pop'n stage in more detail.
  Add web links to the good on-line resources.

 ++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
  DONE		Position window more carefully.
  DONE		Add horizontal grid lines.
  DONE		Add a vertical line every 100 years
  DONE		Add ability to interrupt and alter rates,
                         and add random plagues or wars.
  DONE		Add screensave and print.
  DONE		Add a spinner to control update speed.
  DONE		Add buttons to change rates mid-calculation.
  DONE          Swap colours- pink for boy, blue for girl.
++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

>>
